Coupling Inline White BCG Insulator Half 4mm Hose Barb

1503-3236-000
Anesthesia Delivery
GE HealthCare
Outright
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Prevents both kinked tube and accidental disconnection
  • Easy to clean
  • Reusable
  • Enhanced durability

Product Overview

The Coupling Inline White BCG Insulator Half 4mm Hose Barb is a coupling which connects the adjustable venturi with the flowmeter. The twist to connect coupling provide a more secure and reliable connection. The tube is free to rotate while connected to this coupling. This prevents both kinking of the tube and accidental disconnection while in use. It is used in bulkhead assembly. It is quick disconnect coupling with replaceable O-ring Seal. The O-ring lubricant must be O₂ Compatible. The flowrate will be more than 30 L/min and the maximum pressure will be 100 psi. It is used in the breathing circuit gas system. It is made up of thermoplastic acetal. The material provides high strength and stiffness, good wear and chemical resistance, enhanced dimensional stability and it is easy to machine. These are being used in MS Dash™ 4000, Aespire 7100, MS PDM, ARC Aespire View, MIC Panda™ iRES Warmer, ARC Aestiva 7100, ARC Engstrom Carestation, ARC Airway Gas Module, MS TRAMRAC, ARC Aespire 7100, UL Vivid E95, ARC Aespire 7900, UL LOGIQ E9, Aespire 100, UL Voluson P8, Aespire 7900 and XR Optima XR220amx.

Compatible Products

Aisys

Aisys

Aestiva WU_0042

Aestiva WU_0042

Avance

Avance

Aespire WU_0039

Aespire WU_0039

Aestiva 7900

Aestiva 7900

Aespire 7900

Aespire 7900
