BaseLite Module Assembly
2060229-001
Diagnostic ECG
GE Healthcare
Outright
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Product Overview

The purpose of the BaseLite assembly is to interface between the ML/CL (Mac-Lab/CardioLab) acquisition computer and the PDM. The BaseLite powers the PDM and routes Ethernet signals between the ML/CL acquisition computer and the PDM. This module contains Main BaseLite Board, a 60 watt Power Supply, Power Inlet w/Fuse, Internal Ground Cable (main ground in enclosure), Input Power Cable (connects Power Input to the Power Supply) and DC Power Cable (connects the Power Supply to the Main BaseLite Board). All parts are enclosed in a mechanical enclosure which protects the boards and components. The enclosure comes with the Power Inlet, Ethernet Port, DB9 port and PDM connector for external interfaces. The input power section of the module is fuse protected which provides overcurrent protection. This module can be used with Mac-Lab and CardioLab Recording Systems.
