Head Neck Unit Latch Kit

5365862
Magnetic Resonance Imaging
GE Healthcare
Outright
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Field Replacement Unit (FRU) - can be attached and removed easily
  • Good corrosion resistance
  • Structural stability
  • Flexible

Product Overview

The Head Neck Unit (HNU) Latch Kit includes two separate parts, the posterior latch assembly and the anterior latch assembly. In the posterior latch assembly, the head neck unit is fixed to the latch mount using a latch pin, thus forming a hinge. The screws are inserted to locate against the bottom of the counter bored hole of the latch mount. In the same way, the latch clip and lower latch base are two separate head and necks parts which are connected using the locking pin, springs and screws. The locking pin has a 4.76 mm diameter and 28.58 mm length. This kit is used in the Magnetic Resonance Imaging (MRI) equipment. The head and neck latches are made from the material which has volume resistivity and thermal conductivity. The material used for the latch pin, screws and springs possesses good strength and ductility. The screws are a non-magnetic hardware which comes in different shapes and sizes. They are packed separately in a bag and placed inside the carton box. The box is sealed and wrapped with the tape. It is a Field Replacement Unit (FRU) or spare part which can be replaced whenever required.

Compatible Products

Brivo 355

Brivo 355

Optima 360 1.5T

Optima 360 1.5T

Signa Creator 1.5T

Signa Creator 1.5T

Signa Explorer 1.5T

Signa Explorer 1.5T
