Gryphon Interface Board PWA

5397662
X-Ray
GE HealthCare
Outright
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Enhanced durability
  • Replaceable
  • Can work efficiently in a wide temperature range
  • No special cooling requirement

Product Overview

The Gryphon Interface Board PWA is used in gryphon cabinet assembly which comes under the modality of X-Ray. The Circuit board consists of power converter, Ethernet interface, ARM7 MCU, LPC2468 Extend I/O, CAN&RS-232, Memory, Flash 1MB x 32bit, OR 2MB x 32bit, SDRAM 4M x 32bit, backplane interface, USB interface, RS-422 Interface, Analog input and shunt current detect, RTL input, Relay output, Drive output, Switch output, ARM Reset and watchdog, Jtag port, ISP control, temperature sensor, SPI port, Diff I/O and LED Indicator. The primary functions of the IF board are System power control, Expose control, Magic PC RS232 communication interface, Listen messages from JEDI to Analog console. The board contains several required resistors and capacitors and also includes system control board, gryphon IF board firmware and logic board panel assembly. The GE product is an innovation and fit well into versatile customer needs. The part is diligently designed for superior performance and reliability. It is securely packed inside a high quality packing box to avoid physical damage during transit and labeled with details about the product, Quality Assurance (QA) seal and shipment details.

Compatible Products

Precision 500D

Precision 500D

Robust, digital performance at an efficient dose
It starts with the imaging chain, which features a 12-bit CCD-based camera.Then there’s AutoEx, which automatically adjusts key image-acquisition parameters in real time for optimum quality. Meanwhile, closed-loop Automatic Brightness Control and patented extended Dynamic Range circuitry maintain contrast and minimize blooming.
