DC-DC PS Module Kit - RoHS

5439596
2403248 2416397-2 5396104 S2403248-4
Ultrasound
Other Ultrasound
GE HealthCare
Outright
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Fire retardant
  • Thermal resistant and thermal conductivity
  • Excellent di-electrical properties
  • Tensile strength

Product Overview

The DC-DC Power Supply (PS) Module Kit consists of the DC-DC power supply assembly and a label. The power supply assembly consist of the main board, controller card assembly, front cover, rear cover, top cover and screws. The Power Supply Unit (PSU) includes temperature sensors. When the monitoring application measures the maximum temperature limit or above, it will shut down the system. After the temperature stabilizes, the PSU will enable the DC-DC operation once again. The DC-DC power supply unit is located inside the cabinet cage assembly, provides the Vivid S5™ or Vivid S6™ system with both low voltage and high voltage power and also enables recharging of the battery. It converts the DC voltage from 12V to 5V. The DC-to-DC power supply is also referred to as the HVPS (High Voltage Power Supply). It is being used in XV Advantx LCA, UL VSCAN, XV Innova 2100, UL Vivid I, UL Vivid S5, UL Vivid 7 Pro, UL Vivid q, UL Vivid ICE, UL Voluson S6, UL ABUS Invenia GENII, UL LOGIQ P3 Expert, UL RT 3200, UL Voluson 730 Pro, UL Docking Cart and other applications.

Substitute Parts :

Below is more information on the equivalent parts. Parts without a hyperlink are listed for reference only and are not available for purchase online.

Equivalent partPart Details
2403248

2403248

2416397-2
5396104

5396104

S2403248-4

S2403248-4
